Description
Main Features
- Robust (7ga) 304 stainless steel welded C frame
- Heavy-duty leveling pads and casters
- PLC with full color 7” HMI touch screen
- Stored operational settings as recipes for each cap and container
- First capping spindles can rotate in either forward or reverse direction
- Each spindle is equipped with a readily adjustable torque clutch
- Safely adjust spindle positioning while the machine is in operation, without any hazards
- Spring-loaded spindles for improved cap grip and reduced disc wear
- Each spindle height is individually adjustable
- Side gripper belts with tilting capabilities for tapered bottles
- Safety switches on all doors
- Height adjustability for containers up to 14 inches tall
- Upright feeder fill level sensor
- Electronic maintenance reminders
Specifications
- Cap sizes from 15 mm – 53 mm
- Up to 200 bottles per minute
- Electrical Requirements: 120V / 1 PH / 60 Hz / 15 Amps
- Air Requirements: 90 PSI at 5 CFM
- Machine Footprint: 52.5″ L x 36.0″ W x 95.6″ H
Optional Features
- Cap Elevator
- Additional Spindles
- Dual Gripper Belts
- Right to Left feed
- Power-Driven Height Adjustment
- Vision system for presence and integrity of caps
In-Stock with Pre-Shipment Requirements While this machine is currently in stock, shipment is subject to completion of required pre-shipment activities, including sample evaluation, machine configuration to your specifications, Factory Acceptance Testing (FAT), and setup. These activities generally require approximately 4–6 weeks from the date we receive representative samples. After these steps are concluded, the machine will be crated and prepared for shipment.
