Description
Main Features
- Made in the USA with 100% UL certified components
- Stainless steel frame
- Operates at speeds up to 80 ft/min
- Built-in pinch point protection for operator safety
Technical Data
- Motor: AC Brother gearmotor, 1/10 HP, 90 RPM, 74 in-lbs, 230 VAC 3PH
- VFD: Teco, Input voltage 115 PH / Output voltage 230 VAC / 3PH
- Electrical requirements: 115 V / 1 PH / 60 Hz / 5.7 Amps
- Adjustable belt opening: 0” to 7 3/4”
- Belt size: 36” L x 1” H
- Floor to belt height: 36” to 42” (set at 37”)
- Overall machine dimensions: 38” L x 24 ½” W x 44” H
- Crated weight: 160 lbs
- Crated dimensions: 42” x 32” x 54”
Optional Features
- Print head bracket
- Bottle sliding plate
- Locking casters
Warranty
- 12 months (limited warranty)
